| ＩＧ－２２ＣＧＭ－ＳＲＴ３５０１Ｂ－１２ （１／ｉ） |
| ◆Examples of Applications：Ticket Selling Machines, Door Locks,
Amusement Equipment |
◆GEARED MOTOR
TORQUE/SPEED/CURRENT
| Geared Motor Model>> ＩＧ－２２ＣＧＭ－ＳＲＴ３５０１Ｂ－１２ （１／ｉ） |
Reduction
ratio
1/i |
Rated
torque |
Rated
speed
min-1 |
Rated
current
mA |
No
load
speed
min-1 |
No
load
current
mA |
CW,CCW |
L
mm
|
| mN?m |
kg?cm |
| 1/4 |
9.81 |
0.10 |
1014 |
?235 |
1258 |
?60 |
CW |
53.3 |
| 1/15 |
29.4 |
0.30 |
288 |
?245 |
363 |
↑ |
↑ |
↑ |
| 1/20 |
39.2 |
0.40 |
220 |
?250 |
280 |
↑ |
↑ |
↑ |
| 1/23 |
44.1 |
0.45 |
189 |
?240 |
237 |
↑ |
↑ |
↑ |
| 1/61 |
93.2 |
0.95 |
73 |
?245 |
92 |
↑ |
↑ |
56.5 |
| 1/107 |
98.1 |
1.0 |
46 |
?170 |
53 |
↑ |
↑ |
↑ |
| 1/242 |
147 |
1.5 |
21 |
?150 |
23 |
↑ |
↑ |
59.7 |
| 1/326 |
↑ |
↑ |
16 |
?130 |
17 |
↑ |
↑ |
↑ |
| 1/410 |
196 |
2.0 |
13 |
↑ |
14 |
↑ |
↑ |
↑ |
| 1/483 |
↑ |
↑ |
11 |
?120 |
12 |
↑ |
↑ |
↑ |
| |
：Standard Reduction Ratio |
| *When ordering, please designate a reduction
ratio. |
◆MOTOR INSTALLATION
|
Motor Model>> ＳＣＲ１７－３５０１Ｂ－１２ |
Motor
name
|
Rated
volt
V |
Rated
torque
|
Rated
speed
min-1 |
Rated
current
mA |
No
load
speed
min-1 |
No
load
current
mA |
CW,CCW |
Rated
output
(W) |
| mN?m |
g?cm |
| SCR17-3501B-12 |
12 |
2.94 |
30 |
4700 |
?200 |
5900 |
?20 |
CW |
1.41 |
◆GEARBOXES SPECIFICATIONS
| Gearhead Model>> ＩＧ－２２Ｃ （１／ｉ） |
Reduction
ratio
1/i |
Rated
torque
|
Step |
Efficiency
% |
CW,CCW |
Radial
play
of shaft
mm |
Thrust
play
of shaft
mm |
L
mm
|
Catarog
Data |
Calculated
Data |
mN?m |
kg?cm |
| 1/4 |
1/4.50 |
29.4 |
0.30 |
2 |
81 |
CW |
?0.10 |
?0.35 |
15.5 |
| 1/15 |
1/15.58 |
49.0 |
0.50 |
4 |
66 |
↑ |
↑ |
↑ |
↑ |
| 1/20 |
1/20.25 |
↑ |
↑ |
↑ |
↑ |
↑ |
↑ |
↑ |
↑ |
| 1/23 |
1/23.88 |
↑ |
↑ |
↑ |
↑ |
↑ |
↑ |
↑ |
↑ |
| 1/61 |
1/61.51 |
98.1 |
1.0 |
6 |
53 |
↑ |
↑ |
↑ |
18.7 |
| 1/107 |
1/107.48 |
↑ |
1.0 |
↑ |
↑ |
↑ |
↑ |
↑ |
↑ |
| 1/242 |
1/242.79 |
147 |
1.5 |
8 |
43 |
↑ |
↑ |
↑ |
21.9 |
| 1/326 |
1/326.46 |
↑ |
↑ |
↑ |
↑ |
↑ |
↑ |
↑ |
↑ |
| 1/410 |
1/410.06 |
196 |
2.0 |
↑ |
↑ |
↑ |
↑ |
↑ |
↑ |
| 1/483 |
1/483.66 |
↑ |
↑ |
↑ |
↑ |
↑ |
↑ |
↑ |
↑ |
| |
：Standard Reduction Ratio |
| Notes |
1. The value for a geared motor's current is converted from
the torque, and is a reference value. |
|
2. The above specifications are an example. Please consult
with us about your desired specifications. |
|
3. The turning directions stated in the standard speed reducer
specifications are: CW: same as that of a motor, and CCW: opposite of that of a
motor.
|
|
|
